Description
Specifications:
| Model | TEC-36000HPSD-Q-DCI | TEC-36000HPSD-R-DCI | TEC-48000HPSD-DCI | TEC-60000HPSD-DCI | |
| Power supply | V-ph-HZ | 220-240-1-50 | 380-420-3-50 | 380-415-3-50 | 380-415-3-50 |
| Cooling performance | |||||
| Capacity | Btu/h | 36000 | 36000 | 49000 | 56000 |
| Input | W | 4120 | 3880 | 5128 | 6500 |
| current | A | 18.9 | 6.8 | 9.0 | 11.2 |
| EER | W/W | 2.56 | 2.72 | 2.8 | 2.53 |
| Heating performance | |||||
| Capacity | Btu/h | 40000 | 40000 | 52000 | 62000 |
| Input | W | 3340 | 3247 | 4220 | 5300 |
| current | A | 15.3 | 5.7 | 7.4 | 9.2 |
| COP | W/W | 3.51 | 3.61 | 3.61 | 3.43 |
| Indoor Unit | |||||
| Indoor Air flow (Hi/Mi/Lo) | m3/h | 2148/1810/1648 | 2148/1810/1648 | 2809/2554/2272 | 3150/2809/2554 |
| noise level (Hi/Mi/Lo)indoor | dB(A) | 53/50/47 | 53/50/47 | 51/49/46 | 52/50/48 |
| Dimension (LxWxH) | mm | 110x450x270 | 1100x450x270 | 1200x550x380 | 1200x550x380 |
| Packing (WLxWxH) | mm | 1335x555x340 | 1335x555x340 | 1485x675x450 | 1485x675x450 |
| Net/Gross weight | kg | 31/35.7 | 31.3/36 | 46/52.3 | 45.9/52.2 |
| Drainage water pipe dia | OD25 | OD25 | OD25 | OD25 | |
| Outdoor Unit | |||||
| Dimension (LxWxH) | mm | 990x354x965 | 990x345x965 | 938x392x1369 | 938x392x1369 |
| Packing (WLxWxH) | mm | 1120x435x1100 | 1120x435x1100 | 1095x495x1505 | 1095x495x1505 |
| Net/Gross weight | kg | 75/84.5 | 81/91 | 102/118 | 107/120 |
| Refrigerant type/quantity | |||||
| Type | R410A | R410A | R410A | R410A | |
| Charged volume | kg | 2.6 | 2.4 | 3.25 | 3.2 |
| Refrigerant piping | |||||
| Liquid side/gas side | mm | 9.52/19 | 9.52/19 | 9.52/19 | 9.52/19 |
| (inch) | (3/8″/3/4″) | (3/8″/3/4″) | (3/8″/3/4″) | (3/8″/3/4″) | |
| Max. pipe length | m | 30 | 30 | 50 | 50 |
| Max. difference in level | m | 20 | 20 | 25 | 25 |
